Table load capacity is on average 23% higher compared to other manufacturers of molybdenum-wire EDM machines
The wire rewinding drum, made of special stainless steel and working together with a "Shihlin" (Taiwan) inverter, increases the service life of the molybdenum wire through smooth and even winding, optimal tension force, and gentle acceleration/deceleration
Multi-pass machining to achieve a surface roughness of Ra 1.2-1.5 µm
Can use both molybdenum and tungsten wire
Machining accuracy ± 0.007 mm
The symmetrical design of the UV axes relative to XY, as opposed to a C-shaped design, ensures even wire tension and a minimal wire path to the winding drum; the absence of jerks during travel provides high machining accuracy (± 0.007 mm) and increased wire life
Maximum machining angle ± 15° at a part height of 80 mm (optional)
Machining height up to 500 mm (optional)
CNC-integrated CAM/CAD system based on AutoCAD 2002
