Detailed Engineering Documentation

Detailed engineering documentation translates the process technology concept into a precise set of drawings and specifications that contractors and installation teams can work from. Without complete and accurate documentation, construction and equipment installation are prone to costly errors and delays.

What is included

• General arrangement drawings and floor plans
• Piping and instrumentation diagrams (P&IDs)
• Equipment layout and installation drawings
• Electrical and utility connection schemes
• Equipment specifications and datasheets
• Bill of materials and procurement specifications

How the project proceeds

1. Receive the approved process technology concept and site data
2. Develop general arrangement and layout drawings
3. Produce instrumentation, electrical, and utility schemes
4. Compile the complete documentation package and review with the client

Why Infinity

Our engineering documentation is built around actual equipment that will be procured — not generic placeholders — which reduces the gap between design and reality and eliminates most late-stage changes.
