Hangcha CPD15J-C1 electric forklift is characterized by convenience, reliability, and ergonomic use. In addition, it meets all international regulatory requirements and has the appropriate certificates.
Hangcha CPD15J-C1 has the following technical characteristics:
Hangcha CPD15J-C1 electric forklift is characterized by convenience, reliability, and ergonomic use. In addition, it meets all international regulatory requirements and has the appropriate certificates.
Hangcha CPD15J-C1 has the following technical characteristics:
This forklift is ideal for use in factories and other production facilities, warehouse areas, agriculture, etc.
This model CPD15J-C1 is equipped with an economical and reliable engine. All parts undergo quality control at every stage of production.
Our specialists are ready to offer you a full range of services for selecting Hangcha forklifts. Requests are processed daily. We are always ready to help you in your business.
Price upon request
| Model | Hangcha (HC) CPD15J-C1 | ||||
| Rated Load Capacity | kg | 1500 | |||
| Load Center | mm | 500 | |||
| Lift Height | mm | 3000 | |||
| Free Lift | mm | 135 | |||
| Fork Size | L x W x T | mm | 35x120x900 | ||
| Mast Tilt Range | Forward/Reverse | deg. | 5/10 | ||
| Overall Dimensions | Length to Fork Face | mm | 2080 | ||
| Overall Width | mm | 1060 | |||
| Lowered Mast Height | mm | 1995 | |||
| Extended Mast Height | mm | 3935 | |||
| Overhead Guard Height | mm | 2075 | |||
| Operator Seat Height | mm | 1030 | |||
| Turning Radius | minimum | mm | 1780 | ||
| Overhang | mm | 406 | |||
| Track Width (front/rear) | mm | 888/897.5 | |||
| Ground Clearance | minimum | mm | 110 | ||
| Wheelbase | mm | 1380 | |||
| Fork Spread | minimum/maximum | mm | 240/1000 | ||
| Working Aisle Width with Pallet | 1000x1200 crosswise | mm | 3556 | ||
| 800x1200 lengthwise | mm | 3655 | |||
| Speed | Travel Loaded | km/h | 14 | ||
| Travel Unloaded | km/h | 14 | |||
| Lifting Loaded | mm/h | 300 | |||
| Lifting Unloaded | mm/h | 450 | |||
| Lowering Loaded | mm/h | 460 | |||
| Lowering Unloaded | mm/h | 430 | |||
| Gradeability | Loaded | % | 15 | ||
| Unloaded | % | 16 | |||
| Max. Drawbar Pull (loaded, S2 5 min) | H | 11000 | |||
| Service Weight | including battery | kg | 2940 | ||
| Axle Load (Front/Rear) | loaded | kg | 3900/540 | ||
| unloaded | kg | 1353/1587 | |||
| Wheels | Front | 6.00-9 | |||
| Rear | 5.00-8 | ||||
| Engine | Drive | kW | 6.,8 | ||
| Hydraulic Pump | kW | 8.2 | |||
| Battery | Standard | V/Ah | 48/420 | ||
| Optional | V/Ah | 48/550 | |||
| Controller | Type | AC | |||
| Manufacturer | CURTIS | ||||
| Working Pressure | For Attachments | MPa | 14.5 | ||
